Produktbeskrivelse
|
XFX ProSeries P1-550S-XXB9 - Core Edition - strømforsyning - 550 Watt
|
Enhedstype
|
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
|
Specifikationsoverensstemmelse
|
ATX12V 2.2/ EPS12V 2.91
|
80 PLUS certificering
|
80 PLUS Bronze
|
Indgangspænding
|
AC 100-240 V
|
Udgangspænding
|
+3.3, +5, ±12 V
|
Strømkapacitet
|
550 Watt
|
Output Current
|
+3.3V - 25 A / 0 A ¦ +5V - 25 A / 0 A ¦ +12V - 53 A / 0.6 A ¦ -12V - 0.5 A / 0 A ¦ +5VSB - 3 A / 0 A
|
Output-stikforbindelser
|
1 x strøm 24 pin ATX med aftagelig 4 pin sektion ¦ 1 x strøm 8 pin EPS12 V med aftagelig 4 pin ATX12V sektion ¦ 1 x 6 pin PCI Express-strøm ¦ 1 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion ¦ 9 x 15 pin Serial ATA strøm ¦ 6 x 4-PIN intern strøm ¦ 2 x 4-PIN mini-strømforsyningsforbinder
|
Kølesystem
|
120 mm ventilator
|
Dimensioner (B x D x H)
|
15 cm x 14 cm x 8.6 cm
|
Miljømæssige standarder
|
ENERGY STAR
|
Producentgaranti
|
5 års garanti
|
Produktdatablad |
|
Enhedstype |
Strømforsyning - aktiv Power Factor Correction (PFC) - intern |
Specifikationsoverensstemmelse |
ATX12V 2.2/ EPS12V 2.91 |
PSU formfaktor |
ATX |
Indgangspænding |
AC 100-240 V |
Indgangspændingsområde |
AC 90 - 264 V |
Nødvendig frekvens |
47 - 63 Hz |
Detaljer om strømudgangskonnektorer |
1 x strøm 24 pin ATX med aftagelig 4 pin sektion ¦ 1 x strøm 8 pin EPS12 V med aftagelig 4 pin ATX12V sektion ¦ 1 x 6 pin PCI Express-strøm ¦ 1 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion ¦ 9 x 15 pin Serial ATA strøm ¦ 6 x 4-PIN intern strøm ¦ 2 x 4-PIN mini-strømforsyningsforbinder |
Udgangspænding |
+3.3, +5, ±12 V |
Strømkapacitet |
550 Watt |
Output Current |
+3.3V - 25 A / 0 A ¦ +5V - 25 A / 0 A ¦ +12V - 53 A / 0.6 A ¦ -12V - 0.5 A / 0 A ¦ +5VSB - 3 A / 0 A |
80 PLUS certificering |
80 PLUS Bronze |
Kølesystem |
120 mm ventilator |
Egenskaber |
Overspændingsbeskyttelse, overbelastningsbeskyttelse, SLI klar, CrossFire klar, beskyttelse mod underspænding, kortslutnings beskyttelse, enkelt 12V skinne, køleventilator til kugleleje, ikke-modulær |
Overensstemmelsesstandarder |
RoHS |
ENERGY STAR |
Ja |
Service & Support |
Begrænset garanti - 5 år |
Maks. driftstemperatur |
50 °C |
Bredde |
15 cm |
Dybde |
14 cm |
Højde |
8.6 cm |
Unique, continuous EasyRail technology enables you to maximize available power and make set-up easy. Stack numerous power-hungry components without fear of crashing. It's also a perfect solution for hardcore gamers.
Enables you to maximize available power and make set-up easy. Stack numerous power-hungry components, such as your GPU, CPU and other components, without fear of crashing. In addition this PSU has also been award the 80 Plus Bronze certification for its high power efficiency and is also designed for NVIDIA SLI and AMD Crossfire multi-GPU systems making it a perfect solution for hardcore gamers.
Conventional PSU uses multi-rail technology which basically combines cheaper and lower wattage PSU into one single PSU to generate a higher total wattage. However, smaller rails have lower maximum wattages so left over wattage on individual rails become too small to handle major components and gets wasted.
