Produktbeskrivelse
|
MOXA Transio A53 - medieomsætter - RS-232, RS-422, RS-485
|
Enhedstype
|
Medieomsætter - RJ-45 / RJ-45
|
Model
|
Ekstern
|
Kabeltype
|
Seriel RS-232, seriel RS-422, seriel RS-485
|
Dataoverførselshastighed
|
230.4 Kbps
|
Dataforbindelsesprotokol
|
RS-232, RS-422, RS-485
|
Maks. overføringsafstand
|
1.2 km
|
Dimensioner (B x D x H)
|
9 cm x 6 cm x 2.1 cm
|
Vægt
|
85 g
|
Producentgaranti
|
5 års garanti
|
Produktdatablad |
|
Enhedstype |
Medieomsætter |
Model |
Ekstern |
Forbindelsesteknologi |
Kabling |
Kabeltype |
Seriel RS-232, seriel RS-422, seriel RS-485 |
Dataforbindelsesprotokol |
RS-232, RS-422, RS-485 |
Dataoverførselshastighed |
230.4 Kbps |
Maks. overføringsafstand |
1.2 km |
Statusindikatorer |
Strøm, status |
Egenskaber |
2 KV Optical Isolation Protection, Automatic Data Direction Control (ADDC), 25KV ESD Protector |
Interface |
1 x RS-422/485 - RJ-45 hun ¦ 1 x RS-232 - RJ-45 hun |
Medfølgende ledninger |
1 x seriel adapter |
Overensstemmelsesstandarder |
FCC Klasse A certificeret |
Bredde |
9 cm |
Dybde |
6 cm |
Højde |
2.1 cm |
Vægt |
85 g |
Service & Support |
Begrænset garanti - 5 år |
Min. driftstemperatur |
0 °C |
Maks. driftstemperatur |
55 °C |
Fugtighedsgrad ved brug |
5 - 95% |
The Transio A53 is smart RS-232 to RS-422/485 bi-directional converter that comes with all of the great technical specs that Moxa is known for. This includes data direction control built into the hardware for both the RS-422 and RS-485 interfaces, LED indicators for power and signal states, and surge protection and isolation protection. The last two features take care of some of the major problems faced by serial communication connections in industrial environments.
