Produktdatablad |
|
Enhedstype |
Switch - 24 porte - smart |
Pakningstype |
Desktop, monterbar på stativ |
Undertype |
Gigabit Ethernet |
Porte |
24 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink) |
Præstation |
Skift af båndbredde: 128 Gbps ¦ Videresendelse af båndbredde: 64 Gbps ¦ Videresendelsespræstation (64-byte pakkestørrelse): 41.67 Mpps |
Kapacitet |
VLANs understøttet: 4094 ¦ Aktive VLANer: 64 ¦ STP-instanser: 64 ¦ SPAN-sessioner: 1 |
MAC adresse table størrelse |
8K indtastningshukommelse |
Jumborammesupport |
10240 byte |
Routingprotokol |
IGMP, MLDv2, MLD |
Protokol til fjernadministration |
SNMP 1, RMON 2, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI |
Autentificeringsmetode |
Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
Egenskaber |
DHCP-understøttelse, auto-negotiation, understøttet af BOOTP, understøttet af ARP, auto-uplink (auto MDI/MDI-X), Intrusion Detection System (IDS), Weighted Round Robin (WRR) queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Dynamic ARP Inspection (DAI), Cisco EnergyWise teknologi, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), blæserløs, Link Aggregation Control Protocol (LACP), Port Security, Energy Efficient Ethernet, Management Information Base (MIB), Dynamic VLAN Support (GVRP), Class of Service (CoS), IGMP-filtrering, Weighted Tail Drop (WTD), VLAN Trunking Protocol (VTP), Bridge protocol data unit (BPDU), Internet Control Message Protocol (ICMP), Spanning-tree Root Guard (STRG), Network Timing Protocol (NTP) |
Overensstemmelsesstandarder |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.3az, IEEE 802.1AX |
Processor |
ARM7: 800 MHz |
RAM |
512 MB |
Flashhukommelse |
256 MB |
Statusindikatorer |
Portstatus, dupleksmodus for port, system, PoE, link/hastighed |
Interface |
24 x 1000Base-T RJ-45 ¦ 1 x konsol RJ-45 ¦ 1 x konsol (mini-USB) Type B ¦ 1 x USB Type A ¦ 4 x 10GBase-X SFP+ uplink |
Nødvendig spænding |
AC 120/230 V (50 - 60 Hz) |
MTBF (forventet tid mellem fejl) |
2,412,947 timer |
Overensstemmelsesstandarder |
Plug and Play, CISPR 22 Klasse A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Klasse A, RoHS, UL 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, AS/NZS CISPR22:2004 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 300 386, USGv6 |
Med software |
Cisco IOS LAN Lite |
Bredde |
44.5 cm |
Dybde |
26.5 cm |
Højde |
4.4 cm |
Vægt |
3.35 kg |
Service & Support |
Begrænset garanti - ombytning - livstid - responstid: næste forretningsdag ¦ Teknisk understøttelse - konsultering - 90 dage |
Min. driftstemperatur |
-5 °C |
Maks. driftstemperatur |
45 °C |
Fugtighedsgrad ved brug |
5 - 90% |
Min. lagertemperatur |
-25 °C |
Maks. Opbevaringstemperatur |
70 °C |
Lagerfugtighedsgrad |
5 - 95% |
