Produktdatablad |
|
| Produkttype |
Bundkort - ATX |
| Chipsættype |
Intel B760 |
| Processor-socket |
LGA1700 sokkel |
| Max antal processorer |
1 |
| Kompatible processorer |
(understøtter 12./13. og 14. Generation Intel Core / Pentium Gold / Celeron) |
| Maks. størrelse |
128 GB |
| Teknologi |
DDR4 |
| Bus Clock |
2133 MHz, 2400 MHz, 2666 MHz, 2933 MHz, 3200 MHz, 3333 MHz (O.C.), 3400 MHz (O.C.), 3466 MHz (O.C.), 3600 MHz (O.C.), 3733 MHz (O.C.), 3800 MHz (O.C.), 4000 MHz (O.C.), 4200 MHz (O.C.), 4266 MHz (O.C.), 4400 MHz (O.C.), 4600 MHz (O.C.), 4800 MHz (O.C.), 5000 MHz (O.C.), 5066 MHz (O.C.), 5200 MHz (O.C.), 5333 MHz (O.C.) |
| Understøttet RAM-integritetskon |
Ikke-ECC |
| Registreret eller buffer |
Ikke bufferet |
| Egenskaber |
Dobbelt kanal hukommelses arkitektur, Intel Extreme Memory Profiles (XMP) 3.0 |
| Type |
HD Audio (8-kanaler) |
| Audio codec |
Realtek ALC897 |
| Overensstemmelsesstandarder |
High Definition Audio |
| Netværk controller |
Realtek RTL8125BG |
| Netværks interfaces |
2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3 |
| Ekspansionsåbninger |
1 x CPU ¦ 4 x DIMM 288-pins ¦ 1 x PCIe 4.0 x16 ¦ 3 x PCIe 3.0 x16 (x1 modus) ¦ 1 x PCIe 4.0 x16 (x4-modus) ¦ 1 x M.2 socket (2242/2260/2280/22110 M.2 Key M åbning) ¦ 1 x M.2 socket (2242/2260/2280 M.2 Key M åbning) ¦ 1 x M.2 socket (Key E) |
| Grænseflade (lagring) |
SATA-600 -stikforbindelser: 4 x 7pin Seriel ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -stikforbindelser: 1 x M.2 ¦ SATA-600 / PCIe 4.0 -stikforbindelser: 1 x M.2 |
| Interface |
1 x HDMI ¦ 1 x DisplayPort ¦ 4 x USB 2.0 ¦ 1 x USB-C 3.2 Gen 2 ¦ 2 x USB 3.2 Gen 2 ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 2 x antenne ¦ 1 x audio linje-ud - mini-jack ¦ 1 x mikrofon - mini-jack ¦ 1 x audio linje-ud (centrum/subwoofer) - mini-jack ¦ 1 x audio linje-ud (bagtil) - mini-jack ¦ 1 x audio linje-ind - mini-jack ¦ 1 x SPDIF-ud ¦ PS/2-tastatur/mus |
| Interne interfaces |
4 x USB 2.0 - intern stik ¦ 2 x USB 3.2 Gen 1 - intern stik ¦ 1 x USB-C 3.2 Gen 1 - intern stik ¦ 1 x audio - intern stik ¦ 1 x seriel - intern stik ¦ 1 x SPI - intern stik |
| Strømkontakter |
24-pin hovedstrøm-konnektor, 2 x 8-pins ATX12V stikforbindelser |
| BIOS-egenskaber |
MSI ClickBIOS 5, M-Flash |
| Hardware egenskaber |
Chassis intrusion styring, Extended Heatsink Design, M.2 Shield FROZR, MSI Core Boost, MSI Memory Boost, MSI Audio Boost, Water Pump Header, Digital PWM, MSI Steel Armor, 6 Layer PCB, 2oz Copper PCB, 12+1+1 Phase Power Design, DIY Friendly Design, Surface Mount Technology (SMT) |
| Udstyr inkluderet |
IO-skjold, Wi-Fi-antenne, m.2 screw/standoff-sæt |
| Medfølgende ledninger |
1 x Seriel ATA kabel |
| Med software |
AIDA64 Extreme (60 dages prøvetid), MSI Center, Norton 360 Deluxe (60 dages prøvetid) |
| Overensstemmelsesstandarder |
DisplayPort 1.4 |
| Bredde |
30.48 cm |
| Dybde |
24.348 cm |
| Pakkedetaljer |
Boks |
