Produktdatablad |
|
| Enhedstype |
Solid state-drev - intern |
| Kapacitet |
480 GB |
| Hardware kryptering |
Ja |
| Krypterings algoritme |
3072-bit RSA |
| NAND Flashhukommelses-type |
3D triple-level cell (TLC) |
| Model |
M.2 2280 |
| Grænseflade |
PCIe 4.0 x4 (NVMe) |
| Egenskaber |
Adaptiv termisk overvågning, Read Unrecoverable Bit Error Rate (UBER) 10e-17, Ende-til-ende databeskyttelse, Advanced ECC Engine, avanceret strømtabsbeskyttelses-arkitektur, Secure Execution Environment, Asymmetric Roots of Trust, Strong Asymmetric Key Support, RSA Delegation Key Support, Secure Boot, Key-Based Firmware Update, Key-Based Privileged Access, 176-lags 3D TLC NAND-teknologi, S.M.A.R.T. |
| Bredde |
22 mm |
| Dybde |
80 mm |
| Drive Writes Per Day (DWPD) |
0.9 |
| SSD-udholdenhed |
800 TB |
| Drevklasse |
Read Intensive |
| Intern datahastighed |
5000 MBps (læs) / 700 MBps (skriv) |
| 4KB Random Read |
280000 IOPS |
| 4KB Random Write |
40000 IOPS |
| Gennemsnitsventetid |
30 μs |
| MTBF (forventet tid mellem fejl) |
2,000,000 timer |
| Ikke-korrigerbare fejl |
1 pr. 10^17 |
| Interface |
1 x PCI Express 4.0 x4 (NVMe) - M.2 Card |
| Kompatibel bås |
M.2 2280 |
| Strømforbrug |
7 Watt (læs) ¦ 4.5 Watt (skriv) |
| Overensstemmelsesstandarder |
UL, TUV, VCCI, BSMI CNS 13438 Class B, RRL, ICES-003 Class B, IC, FCC, EN55024 Class B, RoHS, UkrSEPRO, KC, RCM, IEC 60950-1:2005 Second Edition, IEC60950/EN60950, EN 55032 Class B, AS/NZS CISPR 32 Class B, WEEE 2012/19/EC, KCC KN32 Class B, KCC KN35 Class B, BSMI CNS 15663, VCCI 2015.04 Class B, Morocco, EN 60950-1:2005, CNS 15663, 47 CFR Part 15 Class B, UKCA, EN 60950-1:2006+A1:2010+A11:2009 + A12:2011 + A2:2013, SI 2016/1091 Class B, SI 2012/3032 RoHS, EN55032 Class B |
| Service & Support |
Begrænset garanti - ombytning - 1 år |
| Min. driftstemperatur |
0 °C |
| Maks. driftstemperatur |
70 °C |
| Min. lagertemperatur |
-40 °C |
| Maks. Opbevaringstemperatur |
85 °C |
| Fugtighedsgrad ved brug |
5 - 95 % (ikke-kondenserende) |
| Modstandsdygtighed over for stød (non-operativ) |
1500 g @ 0,5 ms |
| Vibration tolerance (non-operativ) |
20 gRMS @ 5-3000 Hz |
| Designet for |
Lenovo ThinkEdge SE450 7D8T ¦ Lenovo ThinkSystem SN550 V2 7Z69 ¦ Lenovo ThinkSystem SR645 7D2X, 7D2Y ¦ Lenovo ThinkSystem SR650 V2 7D15, 7Z72, 7Z73 ¦ Lenovo ThinkSystem SR665 7D2V, 7D2W ¦ Lenovo ThinkSystem SR670 V2 7Z22, 7Z23 ¦ Lenovo ThinkSystem SR860 V2 7D42, 7Z59, 7Z60 ¦ Lenovo ThinkSystem ST50 V2 7D8J, 7D8K ¦ Lenovo ThinkSystem ST650 V2 7Z74, 7Z75 |
