Produktbeskrivelse
|
HPE Aruba 7008 (RW) 100W PoE+ FIPS/TAA - styringsenhed for netværk - TAA-kompatibel
|
Enhedstype
|
Styringsenhed for netværk
|
Formfaktor
|
Ekstern
|
Antal porte
|
8
|
Dataforbindelsesprotokol
|
Ethernet, Fast Ethernet, Gigabit Ethernet
|
Præstation
|
Firewall-gennemløb: 2 Gbps ¦ 3DES kapacitet: 1,2 Gbps ¦ AES-CCM gennemløb: 1,6 Gbps
|
Kapacitet
|
Maksimum antal adgangs punkter: 16 ¦ Maksimalt antal adgangspunkter (fjern): 16 ¦ Samtidige enheder: 1024 ¦ Virtuelle grænseflader (VLANs): 4094 ¦ Aktive firewall sessioner: 16384 ¦ Samtidige GRE-tunneller: 16 ¦ Samtidige IPSec-sessioner: 512 ¦ Samtidige tunnelporte: 512
|
Power Over Ethernet (PoE) understøttet
|
PoE+
|
TAA kompatibel
|
Ja
|
Dimensioner (B x D x H)
|
20.32 cm x 20.32 cm x 4.2 cm
|
Vægt
|
1 kg
|
Produktdatablad |
|
Enhedstype |
Styringsenhed for netværk |
Bredde |
20.32 cm |
Dybde |
20.32 cm |
Højde |
4.2 cm |
Vægt |
1 kg |
Model |
Ekstern |
Antal porte |
8 |
Forbindelsesteknologi |
Kabling |
Dataforbindelsesprotokol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
Præstation |
Firewall-gennemløb: 2 Gbps ¦ 3DES kapacitet: 1,2 Gbps ¦ AES-CCM gennemløb: 1,6 Gbps |
Kapacitet |
Maksimum antal adgangs punkter: 16 ¦ Maksimalt antal adgangspunkter (fjern): 16 ¦ Samtidige enheder: 1024 ¦ Virtuelle grænseflader (VLANs): 4094 ¦ Aktive firewall sessioner: 16384 ¦ Samtidige GRE-tunneller: 16 ¦ Samtidige IPSec-sessioner: 512 ¦ Samtidige tunnelporte: 512 |
Statusindikatorer |
Strøm, status |
Egenskaber |
Auto-negotiation, IPv6 understøttet, IPv4 support, blæserløs |
Interface |
8 x 1000Base-T (PoE+) - RJ-45 ¦ 2 x USB 2.0 ¦ 1 x konsol - RJ-45 ¦ 1 x management (USB) |
MTBF (forventet tid mellem fejl) |
300,000 timer |
Overensstemmelsesstandarder |
C-Tick, CISPR 24, NOM, EN 61000-3-3, EN55024, CB, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, MIC, AS/NZS 3548, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1 Second Edition, KCC, ANATEL, cTUVus, FIPS, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, KN24, AS/NZS CISPR 22 Class B, FCC Part 15 Class B, CAN/CSA C22.2 No. 60950-1 Second Edition, CNS 13438 Class B |
TAA kompatibel |
Ja |
Power Over Ethernet (PoE) understøttet |
PoE+ |
Strømenhed |
Ekstern strømforsyning |
Strømforbrug ved drift |
126 Watt |
Min. driftstemperatur |
0 °C |
Maks. driftstemperatur |
40 °C |
The 7000 series supports Aruba's next-generation mobility firewall with AppRF technology, which continuously evaluates app usage and performance for over 1,500 apps, including cloud and web-based services that are hidden as encrypted or web traffic. It then automatically makes configuration changes in real-time to ensure optimal bandwidth, priority, and network paths in branch and remote offices to safeguard the best possible user experience.
Integration with cloud services such as Palo Alto Networks GlobalProtect and Microsoft Skype for Business make extending security and QoS for mobile unified communications easier and more reliable across the distributed enterprise.
The 7000 series handles other enterprise-critical capabilities like authentication, encryption, IPv4 and IPv6 services, adaptive radio management, ClientMatch, and RFProtect spectrum analysis and wireless intrusion protection. The 7000 series can be deployed in minutes with zero-touch provisioning via cloud-based Aruba Activate, enabling IT to deploy branch locations simpler and more efficiently.
