| Produktbeskrivelse
|
HPE StorageWorks SAN Switch 8/40 Base - switch - 24 porte - monterbar på stativ
|
| Enhedstype
|
Switch - 24 porte
|
| Pakningstype
|
Monterbar på stativ 1U
|
| Undertype
|
Fibre Channel
|
| Porte
|
24 x 8 Gb fiberkanal SFP+
|
| Protokol til fjernadministration
|
SNMP, Telnet, HTTP
|
| Egenskaber
|
Komplet duplex ydeevne, auto-sensing per device, håndterbar
|
| Effekt
|
AC 120/230 V (50/60 Hz)
|
| Dimensioner (B x D x H)
|
42.9 cm x 30.7 cm x 4.3 cm
|
Produktdatablad |
|
| Enhedstype |
Switch - 24 porte |
| Pakningstype |
Monterbar på stativ 1U |
| Undertype |
Fibre Channel |
| Porte |
24 x 8 Gb fiberkanal SFP+ |
| Fiberkanal |
FC-AL, FC-AL-2, FC-FG, FC-FLA, FC-GS-2, FC-PH, FC-PH-2, FC-PH-3, FC-PLDA, FC-SW, FC-VI |
| Protokol til fjernadministration |
SNMP, Telnet, HTTP |
| Autentificeringsmetode |
RADIUS |
| Egenskaber |
Komplet duplex ydeevne, auto-sensing per device, håndterbar |
| Interface |
1 x 100Base-TX RJ-45 administration ¦ 1 x seriel (RS-232) DB-9 administration ¦ 1 x 4 pin USB Type A administration ¦ 40 x SFP+ |
| Strømenhed |
Intern strømforsyning |
| Nødvendig spænding |
AC 120/230 V (50/60 Hz) |
| Medfølgende ledninger |
1 x serielt kabel |
| Rackmonteringspakke |
Inkluderet |
| Med software |
Drivers & Utilities, Brocade Advanced Zoning, Brocade WEB TOOLS, Brocade Fabric OS |
| Bredde |
42.9 cm |
| Dybde |
30.7 cm |
| Højde |
4.3 cm |
| Min. driftstemperatur |
0 °C |
| Maks. driftstemperatur |
40 °C |
| Fugtighedsgrad ved brug |
20 - 85% |
The 8/8 SAN Switch is targeted for small to medium sized enterprises and is ideal for entry-level SANs, and as an edge switch for core-to-edge SAN environments. The 8/8 SAN Switch provides SAN connectivity that simplifies IT management infrastructures, improves system performance, maximizes the value of virtual server deployments, and reduces overall storage costs.
