| Produktbeskrivelse
|
Moxa UC-8162-LX - vægmontering - Cortex-A8 600 MHz - 512 MB - flash 1 GB
|
| Type
|
PC barebone - vægmontering
|
| Processor
|
1 x ARM Cortex-A8 600 MHz
|
| RAM
|
512 MB DDR3 SDRAM
|
| Harddisk
|
Flash 1 GB - SD
|
| Kortlæser
|
Ja
|
| Netværk
|
10Mb LAN, 100Mb LAN
|
| Med OS
|
Debian Linux 3.2
|
| Dimensioner (B x D x H)
|
10.1 cm x 2.7 cm x 12.8 cm
|
| Vægt
|
224 g
|
| Producentgaranti
|
Begrænset garanti - 5 år
|
Produktdatablad |
|
| Type |
PC barebone |
| Produktmodel |
Vægmontering |
| CPU |
ARM Cortex-A8 600 MHz |
| Antal CPU'er |
1 |
| Maks. antal CPU'er |
1 |
| Installeret størrelse |
512 MB |
| Teknologi |
DDR3 SDRAM |
| Type |
Flash |
| Kapacitet |
1 GB |
| Grænsefladetype |
SD |
| Type |
Kortlæser |
| Understøttede flashhukommelseskort |
SD hukommelseskort, SDHC hukommelseskort, SDXC hukommelseskort |
| Monitortype |
Ingen. |
| Ethernet Ports |
2 x Fast-Ethernet |
| Dataforbindelsesprotokol |
Ethernet, Fast Ethernet |
| Holdere |
1 (total) / 1 (fri) x Mini PCIe |
| Interface |
2 x LAN - RJ-45 ¦ 2 x seriel ¦ 1 x USB 2.0 |
| Overensstemmelsesstandarder |
IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, CCC, RoHS, UL 60950-1, EN 60950-1, WEEE, IEC 60068-2-27, FCC Part 15 B Class A, IEC 60068-2-64, GB 17625.1, GB 9254, China RoHS, EN 55022 Class A |
| Med OS |
Debian Linux 3.2 |
| Service & Support |
Begrænset garanti - 5 år |
| Bredde |
10.1 cm |
| Dybde |
2.7 cm |
| Højde |
12.8 cm |
| Vægt |
224 g |
| Min. driftstemperatur |
-10 °C |
| Maks. driftstemperatur |
60 °C |
| Fugtighedsgrad ved brug |
5 - 95 % (ikke-kondenserende) |
The UC-8100 computing platform is designed for embedded data acquisition applications. The computer comes with one or two RS- 232/422/485 serial ports and dual 10/100 Mbps Ethernet LAN ports, as well as a Mini PCIe socket to support cellular modules. These versatile communication capabilities let users efficiently adapt the UC-8100 to a variety of complex communications solutions. The UC-8100 is built around a Cortex-A8 RISC processor that has been optimized for use in energy monitoring systems, but is widely applicable to a variety of industrial solutions. With flexible interfacing options, this tiny embedded computer is a reliable and secure gateway for data acquisition and processing at field sites as well as a useful communication platform for many other large-scale deployments.
