Produktbeskrivelse
|
LSI MegaRAID SAS 9280-16i4e - styreenhed til lagring (RAID) - SATA 6Gb/s / SAS 6Gb/s - PCIe 2.0 x8
|
Enhedstype
|
Styreenhed til lagring (RAID) - indstikskort
|
Bustype
|
PCIe 2.0 x8
|
Interface
|
SATA 6Gb/s / SAS 6Gb/s
|
Dataoverførselshastighed
|
6 Gbit/s
|
Buffer størrelse
|
512 MB
|
Understøttede enheder
|
Harddisk, diskarray (RAID)
|
Antal kanaler
|
20
|
Maks. antal lagerenheder
|
240
|
RAID-niveau
|
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
|
Systemkrav
|
SunSoft Solaris x86, Novell NetWare, Linux, Microsoft Windows 2000, FreeBSD, Microsoft Windows XP, Microsoft Windows Server 2003, Microsoft Windows Vista, Microsoft Windows Server 2008
|
Microsoft Certification
|
Kompatibel med Windows 7
|
Producentgaranti
|
3 års garanti
|
Produktdatablad |
|
Enhedstype |
Styreenhed til lagring (RAID) - indstikskort |
Host Bus |
PCIe 2.0 x8 |
Interface |
SATA 6Gb/s / SAS 6Gb/s |
Dataoverførselshastighed |
6 Gbit/s |
Buffer størrelse |
512 MB |
Understøttede enheder |
Harddisk, diskarray (RAID) |
Antal kanaler |
20 |
Maks. antal lagerenheder |
240 |
RAID-niveau |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
Processor |
LSI LSISAS2108 800 MHz |
Interface |
1 x SATA 6Gb/s / SAS (intern) ¦ 1 x SATA 6Gb/s / SAS 6Gb/s (ekstern) |
Kompatible åbninger |
1 x PCI Express 2.0 x8 |
Udstyr inkluderet |
Simpelt beslag |
Kompatibel med Windows 7 |
Udstyr og software der er "Kompatibel med Windows 7" har Microsofts forsikring i at disse produkter har bestået kompatibilitets- og pålidelighedsprøver med 32-bit og 64-bit Windows 7. |
Overensstemmelsesstandarder |
FCC Klasse B-certificeret, FCC Klasse A certificeret, UL, VCCI, C-Tick, BSMI, EN 60950, EN 61000-3-2, EN55022, RRL, UL 1950, EN 61000-3-3, EN55024, MIC, CSA C22.2 |
Med software |
LSI MegaRAID Management Suite, LSI WebBIOS Configuration Utility, Command Line Interface (CLI), MegaRAID Storage Manager |
OS nødvendig |
SunSoft Solaris x86, Novell NetWare, Linux, Microsoft Windows 2000, FreeBSD, Microsoft Windows XP, Microsoft Windows Server 2003, Microsoft Windows Vista, Microsoft Windows Server 2008 |
Service & Support |
Begrænset garanti - 3 år |
Maks. driftstemperatur |
60 °C |
The MegaRAID SAS 9280-16i4e, with sixteen internal and four external ports, supports up to 240 SATA or SAS drives for both internal drive storage and external JBOD expansion.
