Produktdatablad |
|
| Enhedstype |
Trådløs router |
| Pakningstype |
Desktop |
| Forbindelsesteknologi |
Trådløs, kabling |
| Dataforbindelsesprotokol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, PPP, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frekvensbånd |
2,4 GHz/5 GHz |
| Præstation |
Maksimum datahastighed (2,4 GHz): 300 Mbps ¦ Maksimum datahastighed (5 GHz): 867 Mbps |
| Kapacitet |
IPSec VPN-tunneler: 5 ¦ Virtuelle grænseflader (VLANs): 4096 |
| Netværks/overføselsprotokol |
TCP/IP, PPTP, UDP/IP, NetBEUI/NetBIOS, NTP, ICMP/IP, IPSec, PPPoE, IPoE, ARP, BOOTP, DHCP, DNS, Bonjour, L2TPv3, DDNS, RTP, L2TPv2 |
| Routingprotokol |
BGP-4, RIP-1, RIP-2, BGP, IGMP, VRRP, OSPFv2, GRE, police-baseret routing (PBR) |
| Protokol til fjernadministration |
SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH |
| Krypterings algoritme |
Trippel DES, Blowfish, RC4, MD5, MPPE, AES, IKE, SSL, TLS, SHA-1, PEAP, TTLS, TKIP, WPA, WPA2, CAST-128, AES-CCMP, WPA2-PSK, WPA2-Enterprise, IKEv2, 1024-bit RSA, 2048-bit RSA, 3072-bit RSA, 256-bit SHA, WEP, 256-bit AES-GCM, 4096-bit RSA, 128-bit AES-GCM, 256-bit AES-CBC, 512-bit SHA, FIPS 140, 384-bit SHA, 192-bit AES-GCM, 128-bit AES-CBC, WPA3-Enterprise, WPA3-Personal, 192-bit AES-CBC |
| Autentificeringsmetode |
RADIUS, PAP, CHAP, X.509 certifikater, Radio Service Set ID (SSID), TACACS+, MS-CHAP, MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST, XAUTH autentifikation, RADSEC |
| Egenskaber |
DMZ-port, DHCP-understøttelse, hardwarekryptering, understøttet af BOOTP, understøttet af ARP, aktivitet, understøttet af OCSP, VLAN-understøttet, IGMP snooping, Syslog understøttet, traffic-shaping, pakkefiltrering, ALG-understøttet, DiffServ understøttet, E-mail advarsel, IPv6 understøttet, Intrusion Prevention System (IPS), URL-filtrering, firmware kan opgraderes, til vægmontering, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, IPSec Virtual Private Network (VPN), understøttelse af Wi-Fi-multimedie (WMM), DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), IPSec NAT-Traversal (NAT-T), DHCP server, Multiple SSID support, DNS proxy, port fremsendelse, nulstillingsknap, båndbreddekontrol, 2T2R MIMO teknologi, IPv4 support, blæserløs, DNS server, LACP support, LLDP support, DHCP videresendelse, Stateful Packet Inspection Firewall (SPIF), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), IPSec over HTTPS, SNMP fælde, DNS relæ, DHCP klient, dobbelt firmware-billeder, Space Time Blocking Code (STBC), sky-administreret, metalkabinet, Type of Service (ToS), IP-spoofing, beskyttee administrationsrammer, VLAN Double Tagging (Q-in-Q), DNS-klient, NTP-klient, Fast Roaming, Simple Certificate Enrollment Protocol (SCEP), Denial of Service (DoS) protection, Advanced Routing and Forwarding (ARF), dynamisk DNS-klient, SNTP-server, Bonjour proxy, CLIP-support, CLIR-support, Calling Line Identification Restriction (CLIR), IPv4 og IPv6 dobbelt stak |
| Overensstemmelsesstandarder |
IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11w, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, EN 60950-1, IP54, IP67, EN 300 328, EN 301 489-1, EN 301 893, SSL, EN 301 489-17 |
| Liniekodningsformat |
256 QAM |
| Type |
ISDN / DSL modem kombination |
| Protokol for digital signaltransmission |
ADSL, VDSL, ADSL2, ADSL2+, VDSL2 |
| Protokoller og specifikationer |
ITU G.992.1 (G.DMT) Annex B, ITU G.993.2, ITU G.992.5 Annex B, ITU G.993.5 |
| Maks. overførselshastighed |
100 Mbps |
| VoIP-protokoller |
SIP, RTP, SRTP |
| Voice Codecs |
G.722, G.723, G.729, G.711u, G.711a, G.726, iLBC, T.38 |
| IP-telefonifunktioner |
Echo cancellation (G.168) (eliminerer ekko), viderestilling af opkald, samtaleparkering, overførsel af samtale, SIP trunking, Calling Line Identification Restriction (CLIR), flimmerbuffer, DTMF inband |
| Interface |
LAN: 1 x 10Base-T/100Base-TX/1000Base-T ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T ¦ 1 x ISDN ¦ WAN: 1 x VDSL2 / ADSL2+ |
| Nødvendig spænding |
AC 230V |
| Strømforbrug ved drift |
20 Watt |
| Udstyr inkluderet |
Vægmonteringssæt |
| Medfølgende ledninger |
2 x netværkskabel - 3 m ¦ 1 x modemkabel - 2 m ¦ 1 x modemkabel - 3 m |
| Lokalisering |
Europa |
| Med OS |
LCOS |
| Bredde |
15.8 cm |
| Dybde |
25 cm |
| Højde |
5.5 cm |
| Service & Support |
Begrænset garanti - 3 år |
| Min. driftstemperatur |
-25 °C |
| Maks. driftstemperatur |
70 °C |
| Fugtighedsgrad ved brug |
0 - 95% (ikke-kondenserende) |
