Produktdatablad |
|
Enhedstype |
Switch - 12 porte - smart |
Pakningstype |
Desktop, monterbar på stativ |
Undertype |
10 Gigabit Ethernet |
Porte |
10 x 10 Gigabit SFP+ + 2 x combo 10 Gigabit SFP+/RJ-45 |
Præstation |
Omkoblingskapacitet: 240 Gbps ¦ Fremsendelsespræstation: 178,56 Mpps |
Kapacitet |
VLAN-grupper: 4000 ¦ ACL-regler: 256 ¦ Statiske ARP-indtastninger: 768 ¦ IPv4 ruter (statisk): 64 ¦ IPv6 ruter (statisk): 64 ¦ IGMP-grupper: 384 ¦ QoS hardware-køer pr. port: 8 ¦ Pakkebufferstørrelse: 2 MB |
MAC adresse table størrelse |
16K indtastningshukommelse |
Jumborammesupport |
9KB |
Routingprotokol |
IGMPv2, IGMP, IGMPv3, statisk IPv4 routing, statisk IPv6 routing, MLDv2, MLD |
Protokol til fjernadministration |
SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI, ICMP, DHCP |
Krypterings algoritme |
SSL, TLS, SSL 3.0, SSL 2.0, PEAP, TTLS |
Autentificeringsmetode |
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
Egenskaber |
Datatransport, understøttet af BOOTP, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack beskyttelse, portspejling, gem og send, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, SNTP-understøttet, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, MDL snooping, Dynamic ARP Inspection (DAI), Safeguard Engine, Cable Diagnostics Function, båndbreddekontrol, D-Link Green Technology, Deficit Weighted Round Robin (DWRR), LLDP support, DHCP videresendelse, IP-MAC binding, SNMP fælde, DHCP klient, Dynamic VLAN Support (GVRP), Strict Priority Queuing (SPQ), Class of Service (CoS), Type of Service (ToS), DiffServ Code Point (DSCP) support, Ethernet Ring Protection Switching (ERPS), systemlog, IP-kildebekyttelse, Deficit Round Robin (DRR), dobbelt billedsupport, Authentication, Authorization and Accounting (AAA), Weighted Deficit Round Robin (WDRR), Web-based Access Control (WAC), DNS-klient, Voice VLAN, LLDP-MED, Guest VLAN, Weighted Round Robin (WRR), DSCP based CoS, Head-of-line (HOL) Blocking Prevention, tilbageløkke-detektion, One-Time Password (OTP), Asymmetric VLAN, Duplicate Address Detection (DAD) |
Overensstemmelsesstandarder |
IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3an, IEEE 802.3az |
Statusindikatorer |
Strøm, blæser, konsol, link/aktivitet/hastighed |
Interface |
10 x 10GBase-X SFP+ ¦ 2 x 10GBase-T/10GBase-X RJ-45/SFP+ ¦ 1 x administration RJ-45 konsol |
Strømenhed |
Intern strømforsyning |
Nødvendig spænding |
AC 100-240 V (50/60 Hz) |
Elektrisk strøm påkrævet |
1.1 A |
Strømforbrug ved drift |
43.81 Watt |
Strømforbrugs-stand by |
25.22 Watt |
Overensstemmelsesstandarder |
VCCI, C-Tick, BSMI, cUL, CB, CCC, FCC |
Lokalisering |
Europa |
Bredde |
44 cm |
Dybde |
21 cm |
Højde |
4.4 cm |
Vægt |
2.73 kg |
Service & Support |
Begrænset garanti - livstid |
Min. driftstemperatur |
-5 °C |
Maks. driftstemperatur |
50 °C |
Fugtighedsgrad ved brug |
0 - 95% (ikke-kondenserende) |
Min. lagertemperatur |
-40 °C |
Maks. Opbevaringstemperatur |
70 °C |
Lagerfugtighedsgrad |
0 - 95% (ikke-kondenserende) |
