Produktdatablad |
|
| Enhedstype |
Switch - 24 porte - Administreret |
| Pakningstype |
Desktop, monterbar på stativ 1U |
| Undertype |
Gigabit Ethernet |
| Porte |
24 x 10/100/1000 (PoE+) + 2 x Gigabit SFP |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE-budget |
185 W |
| Præstation |
Skift af produktion: 52 Gbps ¦ Skift af produktion: 38.7 Mpps |
| Kapacitet |
VLANs understøttet: 1024 ¦ LAG-grupper: 6 ¦ ACL: 100 ¦ Trafiktimer (køer): 8 ¦ IPv4 ruter (statisk): 60 ¦ MSTP-tilfælde: 4 |
| MAC adresse table størrelse |
16.000 indlæg |
| Routingprotokol |
Statisk IPv4 routing |
| Protokol til fjernadministration |
SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, CLI |
| Krypterings algoritme |
TLS 1.0, SSL 3.0 |
| Autentificeringsmetode |
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Egenskaber |
Datatransport, understøttet af ARP, VLAN-understøttet, IGMP snooping, portspejling, DiffServ understøttet, E-mail advarsel, MAC-adresse-filtrering, Broadcast Storm Control, IPv6 understøttet, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Jumbo Frames support, Equal-Cost Multipath (ECMP), STP Root Guard, Uni-Directional Link Detection (UDLD), LLDP support, Remote Switch Port Analyzer (RSPAN), dynamisk IP modus, Management Information Base (MIB), MAC adresse lockout, Multicast VLAN Registration (MVR), Class of Service (CoS), mærket VLAN, Generic Attribute Registration Protocol (GARP), GARP VLAN Registration Protocol (GVRP), Type of Service (ToS), DiffServ Code Point (DSCP) support, 1,5 MB pakkebuffer, Internet Control Message Protocol (ICMP), Secure Copy (SCP), GARP Multicast Registration Protocol (GMRP), Link Aggregation, Management Information Base (MIB) II, Authentication, Authorization and Accounting (AAA), Voice VLAN, LLDP-MED, Guest VLAN, STP BPDU Guard, Industry Standard Discovery Protocol, beskyttede porte, Internal Authentication Server, STP-løkkeværn |
| Overensstemmelsesstandarder |
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at |
| Processor |
1 x ARM Cortex-A9: 400 MHz |
| RAM |
512 MB |
| Flashhukommelse |
128 MB |
| Interface |
24 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-X SFP ¦ 1 x seriel RJ-45 ¦ 1 x administration (LAN) RJ-45 |
| Strømenhed |
Intern strømforsyning |
| Strømforbrug ved drift |
243 Watt |
| Overensstemmelsesstandarder |
CB, AS/NZS 60950-1, CCC, EMC, ICES-003 Klasse A, FCC, UL 60950-1 Second Edition, KCC, CDRH, CSA C22.2 No. 60950-1 Second Edition, VCCI Class A, EN 61000-4-2:2009, EN 61000-4-11:2004, EN 300 386 V1.6.1, RoHS 2011/65/EU, 21 CFR 1040.10, IEC 61000-4-2:2008, IEC 61000-4-11:2004, EN 61000-3-3:2013, EN 55024:2010, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-6:2014, WEEE 2012/19/EU, China RoHS SJ/T 11364-2006, EMC 2014/30/EU, EN 61000-3-2:2014, EN 61000-4-5:2014, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 60825-1:2007, FCC CFR47 Part 15 B Class A, LVD 2014/35/EU, EN 61000-4.4:2012, IEC 60825-1:2007 Class 1, ANSI/TIA-1057, ETSI EN 300 019-2-3 V2.1.2, ETSI EN 300 019-2-2 V2.1.2, EN/ETSI 300 019-2-1 v2.1.2, EN/ETSI 300 753, ASTM D3580, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 Second Edition, EN 55032:2015 Class A, CISPR 32:2015 Class A, CISPR 24:2010 Class A, IEC 61000-4-3:2010, IEC 61000-4-4:2012, IEC 61000-4-5:2014, IEC 61000-4-6:2013, ACMA RCM, AS/NZS CISPR 32 |
| Bredde |
44.1 cm |
| Dybde |
25.4 cm |
| Højde |
4.4 cm |
| Vægt |
3.68 kg |
| Service & Support |
Begrænset garanti - livstid |
| Min. driftstemperatur |
0 °C |
| Maks. driftstemperatur |
50 °C |
| Fugtighedsgrad ved brug |
10 - 95 % (ikke-kondenserende) |
| Min. lagertemperatur |
-40 °C |
| Maks. Opbevaringstemperatur |
70 °C |
| Lagerfugtighedsgrad |
10 - 95 % (ikke-kondenserende) |
