D-Link DGS 3130-30S
D-Link DGS 3130-30S
6.195,- DKK
(4.956,00 ekskl. moms)
| Produktbeskrivelse | D-Link DGS 3130-30S - switch - 30 porte - Administreret |
| Enhedstype | Switch - 30 porte - L3 Lite - Administreret - kan stables |
| Undertype | Gigabit Ethernet |
| Porte | 30 x SFP + 2 x 10 Gigabit Ethernet + 4 x 10 Gigabit SFP+ |
| Præstation | Omkoblingskapacitet: 168 Gbps ¦ Videresendelsespræstation (64-byte pakkestørrelse): 125 Mpps |
| Kapacitet | Pakkebufferstørrelse: 2 MB ¦ Enheder per virtuel stak: op til 32 ¦ IGMP-grupper: 1024 ¦ Virtuelle grænseflader (VLANs): 4000 ¦ QoS hardware køer: 8 |
| MAC adresse table størrelse | 16.384 indtastninger |
| Jumborammesupport | 9KB |
| Routingprotokol | RIP-1, RIP-2, IGMPv2, IGMP, VRRP, IGMPv3, statisk IPv4 routing, statisk IPv6 routing, RIPng, MLDv2, MLD |
| Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH-2, CLI, NTP |
| Egenskaber | Datatransport, understøttet af BOOTP, IGMP snooping, portspejling, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, MDL snooping, Cable Diagnostics Function, båndbreddekontrol, LLDP support, DHCP videresendelse, Port Security, DHCP klient, Strict Priority (SP), Single IP Management (SIM), Ethernet Ring Protection Switching (ERPS), 3 blæsere, IGMP-filtrering, systemlog, Internet Control Message Protocol (ICMP), Management Information Base (MIB) II, Authentication, Authorization and Accounting (AAA), VLAN Double Tagging (Q-in-Q), Web-based Access Control (WAC), DNS-klient, proxy ARP, Energy-Efficient Ethernet (EEE), BPDU Filter, Weighted Round Robin (WRR), Head-of-line (HOL) Blocking Prevention, tilbageløkke-detektion, Telnet-server, Telnet-klient, Root Restriction |
| Overensstemmelsesstandarder | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Effekt | AC 120/230 V (50/60 Hz) |
| Overskudsspænding | Valgfri |
| Dimensioner (B x D x H) | 44 cm x 25 cm x 4.4 cm |
| Vægt | 3.21 kg |
| Enhedstype | Switch - 30 porte - L3 Lite - Administreret - kan stables |
| Undertype | Gigabit Ethernet |
| Porte | 30 x SFP + 2 x 10 Gigabit Ethernet + 4 x 10 Gigabit SFP+ |
| Præstation | Omkoblingskapacitet: 168 Gbps ¦ Videresendelsespræstation (64-byte pakkestørrelse): 125 Mpps |
| Kapacitet | Pakkebufferstørrelse: 2 MB ¦ Enheder per virtuel stak: op til 32 ¦ IGMP-grupper: 1024 ¦ Virtuelle grænseflader (VLANs): 4000 ¦ QoS hardware køer: 8 |
| MAC adresse table størrelse | 16.384 indtastninger |
| Jumborammesupport | 9KB |
| Max antal enheder i en stak | 12 |
| Routingprotokol | RIP-1, RIP-2, IGMPv2, IGMP, VRRP, IGMPv3, statisk IPv4 routing, statisk IPv6 routing, RIPng, MLDv2, MLD |
| Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH-2, CLI, NTP |
| Krypterings algoritme | SSL, SSL 3.0, SSL 2.0 |
| Autentificeringsmetode | Secure Shell v.2 (SSH2) |
| Egenskaber | Datatransport, understøttet af BOOTP, IGMP snooping, portspejling, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, MDL snooping, Cable Diagnostics Function, båndbreddekontrol, LLDP support, DHCP videresendelse, Port Security, DHCP klient, Strict Priority (SP), Single IP Management (SIM), Ethernet Ring Protection Switching (ERPS), 3 blæsere, IGMP-filtrering, systemlog, Internet Control Message Protocol (ICMP), Management Information Base (MIB) II, Authentication, Authorization and Accounting (AAA), VLAN Double Tagging (Q-in-Q), Web-based Access Control (WAC), DNS-klient, proxy ARP, Energy-Efficient Ethernet (EEE), BPDU Filter, Weighted Round Robin (WRR), Head-of-line (HOL) Blocking Prevention, tilbageløkke-detektion, Telnet-server, Telnet-klient, Root Restriction |
| Overensstemmelsesstandarder | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Interface | 24 x 1000Base-X SFP ¦ 2 x 10GBase-T RJ-45 ¦ 4 x 10GBase-X SFP+ ¦ 1 x 10/100/1000 Base-T RJ-45 konsol ¦ 1 x 10/100/1000 Base-T RJ-45 administration ¦ 1 x USB 2.0 Type A |
| Strømenhed | Intern strømforsyning - hot-plug |
| Overskudsspænding | Valgfri |
| Nødvendig spænding | AC 120/230 V (50/60 Hz) |
| Strømforbrug ved drift | 82.4 Watt |
| MTBF (forventet tid mellem fejl) | 487,153 timer |
| Overensstemmelsesstandarder | FCC Klasse A certificeret, BSMI, cUL, CB, CCC, IC, VCCI Class A, RCM |
| Med software | Standard Image (SI) Software |
| Bredde | 44 cm |
| Dybde | 25 cm |
| Højde | 4.4 cm |
| Vægt | 3.21 kg |
| Min. driftstemperatur | 0 °C |
| Maks. driftstemperatur | 50 °C |
| Fugtighedsgrad ved brug | 10 - 90% |
| Min. lagertemperatur | -40 °C |
| Maks. Opbevaringstemperatur | 70 °C |
| Lagerfugtighedsgrad | 90% |
The DGS-3130 Series switches are Lite Layer 3 Stackable Managed Switches designed to connect end-users in a secure enterprise or metro Ethernet access network. These switches support multicast, and enhanced security, making them an ideal Gigabit access layer solution.
