D-Link DGS 3000-28X - switch - 24 porte - Administreret - monterbar på stativ
Produktbeskrivelse | D-Link DGS 3000-28X - switch - 24 porte - Administreret - monterbar på stativ |
Enhedstype | Switch - 24 porte - Administreret - kan stables |
Pakningstype | Monterbar på stativ 1U |
Undertype | Gigabit Ethernet |
Porte | 24 x 10/100/1000 + 4 x 10Gb Ethernet SFP+ |
Præstation | Omkoblingskapacitet: 128 Gbps ¦ Videresendelsespræstation (64-byte pakkestørrelse): 95.24 Mpps |
MAC adresse table størrelse | 16K indtastningshukommelse |
Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, SSH |
Egenskaber | Datatransport, auto-negotiation, understøttet af ARP, trunking, VLAN-understøttet, auto-uplink (auto MDI/MDI-X), DoS attack beskyttelse, Dying Gasp support, Quality of Service (QoS), Safeguard Engine, Network Access Protection (NAP), LLDP support, Remote Switch Port Analyzer (RSPAN), Class of Service (CoS), D-Link Single IP Management (SIM), Ethernet Ring Protection Switching (ERPS), 1,5 MB pakkebuffer, 6 KV strømstødsbeskyttelse, VLAN-spejling, Web-based Access Control (WAC), Connectivity Fault Management (CFM), Extensive Access Control List (ACL) support, Guest VLAN |
Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.1AX |
Effekt | AC 120/230 V (50/60 Hz) |
Dimensioner (B x D x H) | 44 cm x 21 cm x 4.4 cm |
Vægt | 2 kg |
Produktdatablad |
|
Enhedstype | Switch - 24 porte - Administreret - kan stables |
Pakningstype | Monterbar på stativ 1U |
Undertype | Gigabit Ethernet |
Porte | 24 x 10/100/1000 + 4 x 10Gb Ethernet SFP+ |
Præstation | Omkoblingskapacitet: 128 Gbps ¦ Videresendelsespræstation (64-byte pakkestørrelse): 95.24 Mpps |
MAC adresse table størrelse | 16K indtastningshukommelse |
Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, SSH |
Egenskaber | Datatransport, auto-negotiation, understøttet af ARP, trunking, VLAN-understøttet, auto-uplink (auto MDI/MDI-X), DoS attack beskyttelse, Dying Gasp support, Quality of Service (QoS), Safeguard Engine, Network Access Protection (NAP), LLDP support, Remote Switch Port Analyzer (RSPAN), Class of Service (CoS), D-Link Single IP Management (SIM), Ethernet Ring Protection Switching (ERPS), 1,5 MB pakkebuffer, 6 KV strømstødsbeskyttelse, VLAN-spejling, Web-based Access Control (WAC), Connectivity Fault Management (CFM), Extensive Access Control List (ACL) support, Guest VLAN |
Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.1AX |
Statusindikatorer | Strøm, RPS (Redundant Power Supply), blæser, konsol, link/aktivitet/hastighed |
Interface | 24 x 1000Base-T RJ-45 ¦ 4 x 10GBase-X SFP+ ¦ 1 x konsol RJ-45 administration |
Strømenhed | Intern strømforsyning |
Nødvendig spænding | AC 120/230 V (50/60 Hz) |
Strømforbrug ved drift | 22.1 Watt |
Udstyr inkluderet | 4 gummifødder |
Medfølgende ledninger | 1 x konsolkabel |
Rackmonteringspakke | Inkluderet |
MTBF (forventet tid mellem fejl) | 652,062 timer |
Overensstemmelsesstandarder | VCCI, C-Tick, BSMI, cUL, IEC 61000-4-5, CB, FCC, ITU-T G.8032 |
Bredde | 44 cm |
Dybde | 21 cm |
Højde | 4.4 cm |
Vægt | 2 kg |
Min. driftstemperatur | -5 °C |
Maks. driftstemperatur | 50 °C |
Fugtighedsgrad ved brug | 0 - 95% (ikke-kondenserende) |
Min. lagertemperatur | -20 °C |
Maks. Opbevaringstemperatur | 70 °C |
Lagerfugtighedsgrad | 0 - 95% (ikke-kondenserende) |
28-Port Gigabit Layer 2 Managed Switch including 4 x 10GE SFP+ ports. The DGS-3000 Series Gigabit L2 Managed Switches feature a variety of ports, including 10/100/1000BASE-T RJ-45 ports, 1G SFP ports, and 10G SFP+ ports for increased network bandwidth. Surge protection, advanced Layer 2 functions, and a suite of security and management tools make the DGS-3000 Series Gigabit L2 Managed Switches ideal for Metro Ethernet and campus applications.
