Produktbeskrivelse
|
ComNet CopperLine CLRFE4POEC REMOTE UNIT - netværksforlænger - 10Mb LAN, 100Mb LAN
|
Enhedstype
|
Netværksforlænger
|
Antal porte
|
4
|
Model
|
Ekstern
|
Kabeltype
|
10Base-T, 100Base-TX
|
Dataoverførselshastighed
|
100 Mbps
|
Dataforbindelsesprotokol
|
10Mb LAN, 100Mb LAN
|
Power Over Ethernet (PoE)
|
PoE+
|
Dimensioner (B x D x H)
|
15.5 cm x 13.5 cm x 2.8 cm
|
Vægt
|
900 g
|
Producentgaranti
|
Begrænset livtidsgaranti
|
Produktdatablad |
|
Enhedstype |
Netværksforlænger |
Model |
Ekstern |
Antal porte |
4 |
Forbindelsesteknologi |
Kabling |
Kabeltype |
10Base-T, 100Base-TX |
Dataforbindelsesprotokol |
10Mb LAN, 100Mb LAN |
Dataoverførselshastighed |
100 Mbps |
Overensstemmelsesstandarder |
IEEE 802.3af, IEEE 802.3at |
Interface |
4 x Ethernet 10Base-T/100Base-TX - RJ-45 hun ¦ 4 x netværk - BNC hun |
Overensstemmelsesstandarder |
FCC Part 15, RoHS, cULus |
Power Over Ethernet (PoE) |
PoE+ |
Bredde |
15.5 cm |
Dybde |
13.5 cm |
Højde |
2.8 cm |
Vægt |
900 g |
Service & Support |
Begrænset garanti - livstid |
Min. driftstemperatur |
-40 °C |
Maks. driftstemperatur |
75 °C |
Fugtighedsgrad ved brug |
0 - 95% (ikke-kondenserende) |
The ComNet CopperLine Ethernet over copper line supports up to sixteen channels of 10/100 Mbps Ethernet with PoE+ Power Injection and Pass-through PoE+ over twisted pair cable (CAT-5, UTP) or over coax. With the ability to connect directly to a PoE+ switch, or the ability to generate PoE+ power with a 48 to 56 V input to the Remote ends, these units provide the ultimate flexibility for extending a powered device (PD) over long distance copper.
