Cisco Industrial Router 910 - router - DIN monterbar på skinne, væg-monterbar, stangmonterbar
Produktbeskrivelse | Cisco Industrial Router 910 - router - DIN monterbar på skinne, væg-monterbar, stangmonterbar |
Enhedstype | Router |
Pakningstype | DIN monterbar på skinne, væg-monterbar, stangmonterbar - modulær |
Mobilprotokol | HSPA |
Antal WAN porte | 2 |
Dataforbindelsesprotokol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Netværks/overføselsprotokol | TCP/IP, PPTP, UDP/IP, L2TP, IPSec, PPPoE |
Protokol til fjernadministration | SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI |
Egenskaber | NAT-understøtning, VLAN-understøttet, Syslog understøttet, IPv6 understøttet, RADIUS support, DHCP server, blæserløs, DNS server, LLDP support, DHCP klient, grov, 1T1R MIMO-teknologi |
Dimensioner (B x D x H) | 15.7 cm x 12.9 cm x 13 cm |
Lokalisering | Kina, Singapore, Europa |
Produktdatablad |
|
Enhedstype | Router |
Pakningstype | DIN monterbar på skinne, væg-monterbar, stangmonterbar - modulær |
Forbindelsesteknologi | Trådløs, kabling |
Dataforbindelsesprotokol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Netværks/overføselsprotokol | TCP/IP, PPTP, UDP/IP, L2TP, IPSec, PPPoE |
Protokol til fjernadministration | SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI |
Krypterings algoritme | RSA, WPA, WPA2, WEP |
Autentificeringsmetode | RADIUS |
Egenskaber | NAT-understøtning, VLAN-understøttet, Syslog understøttet, IPv6 understøttet, RADIUS support, DHCP server, blæserløs, DNS server, LLDP support, DHCP klient, grov, 1T1R MIMO-teknologi |
Overensstemmelsesstandarder | FCC Part 15 B, UL 60950-1, IEC 60950-1, EN 60950-1, IEC 60068-2-6, IP30, IEC 60950-22, EN 60950-22, UL 60950-22, UL 50E, CAN/CSA-C22.2 No. 60950-1 |
Processor | 1 x 1 GHz |
RAM | 1 GB DDR2 SDRAM |
Flashhukommelse | 2 GB |
Statusindikatorer | Portstatus, system, trådløs, 3G, VPN, seriel |
Mobilprotokol | HSPA |
Interface | Antenne: 1 x ¦ WAN / LAN: 1 x 1000Base-T - RJ-45 ¦ WAN / LAN: 1 x 1000Base-X - SFP (mini-GBIC) ¦ Seriel: 2 x RS-232/485 - RJ-45 ¦ Lederskab: 1 x konsol - RJ-45 ¦ USB 2.0: 1 x 4 pin USB Type A |
Ekspansionsåbninger | 2 (total) / 2 (fri) x ekspansionsåbning |
Strømforbrug ved drift | 12 Watt |
MTBF (forventet tid mellem fejl) | 200,000 time(r) |
Lokalisering | Kina, Singapore, Europa |
Med OS | Linux |
Bredde | 15.7 cm |
Dybde | 12.9 cm |
Højde | 13 cm |
Min. driftstemperatur | -40 °C |
Maks. driftstemperatur | 70 °C |
Fugtighedsgrad ved brug | 5 - 95 % (ikke-kondenserende) |
The Cisco 910 industrial router is part of the Cisco 900 Series industrial routers family. This rugged sensor gateway aggregates both the wireless sensor networks (WSN) and wired sensors and ties them into the IP network. Offering an open hardware/software platform, the IR910 can quickly and easily host partner applications and sensor communication cards. Use the IR910 for local WSN management, raw data collection, caching, processing, and forwarding to data centers in the cloud through a WAN IP interface.
With a modular and open-slot design, the Cisco IR910 provides a common sensor gateway platform to adapt to a variety of wired/wireless sensor technologies for different use cases with benefits including less development effort, quick time to market, and Cisco IP domain expertise. Offering a programmable environment and sufficient headroom of CPU horsepower, memory, and storage, the IR910 natively complies with Cisco Fog Computing architecture, executes distributed data processing at the edge of an IP network, and allows you to host partners' applications.
