Produktdatablad |
|
Enhedstype |
Ekspansionsmodul |
Model |
Indstiksmodul |
Forbindelsesteknologi |
Kabling |
Kabeltype |
Ethernet 10GBase-X |
Dataforbindelsesprotokol |
10 Gigabit Ethernet |
Dataoverførselshastighed |
40 Gbps |
Præstation |
Skift af stofbåndbredde: 80 Gbps ¦ Fremsendelsespræstation: 60 Mpps |
Kapacitet |
Multicas indgange (IPv4): 64000 ¦ Multicast indgange (IPv6): 64000 ¦ Hardware forwarding indgange: 256000 ¦ NetFlow indtastninger: 1000000 ¦ ACL-bidrag: 64000 |
MAC adresse table størrelse |
128K indtastningshukommelse |
Protokol til fjernadministration |
RMON, SMON |
Statusindikatorer |
Status, link/aktivitet |
Egenskaber |
Understøttet af MPLS, IGMP snooping, LLQ, CBWFQ, WRED, ACL support, QoS, Jumbo Frames support, MDL snooping, DWRR, SRR, NetFlow, VPLS |
Overensstemmelsesstandarder |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3ak, IEEE 802.1ae, IEEE 802.3an, IEEE 802.3aq |
RAM |
2 GB |
Ekspansionsåbninger |
4 (total) / 4 (fri) x ekspansionsåbning |
Krypterings algoritme |
128-bit AES |
Overensstemmelsesstandarder |
CISPR 22 Klasse A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Klasse A, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 A, IEC 60825-1, EN 60825-1, GR-1089-CORE, CAN/CSA C22.2 No. 60950, VCCI Class A, CNS 13438(95) Class A, GR-63-CORE, KN22 Class A, ETS 300 386, AS/NZS CISPR 22, ETSI 300 019, 21 CFR 1040.10, EN 55022 Class A |
Strømforbrug ved drift |
303.68 Watt |
OS nødvendig |
Cisco IOS 15.2(1)SY |
Bredde |
39.11 cm |
Dybde |
41.65 cm |
Højde |
4.39 cm |
Vægt |
5 kg |
Min. driftstemperatur |
0 °C |
Maks. driftstemperatur |
40 °C |
Fugtighedsgrad ved brug |
10 - 90 % (ikke-kondenserende) |
Designet for |
Cisco Catalyst 6503-E, 6503-E chassis with Supervisor Engine 32, 6503-E Firewall Security System Bundle, 6503-E WSLM Bundle, 6504-E, 6504-E Application Control Engine (ACE) 20 Bundle, 6504-E chassis with Supervisor Engine 32, 6504-E with Supervisor Engine 720-3B, 6504-E with WiSM Bundle, 6506-E, 6506-E chassis with Supervisor Engine 32, 6506-E Data Center Services Bundle, 6506-E Firewall Security System Bundle, 6506-E IDSM-2 Bundle with 2-Gbps Performance, 6506-E IPSec VPN SPA Security System Bundle, 6506-E NAM-3 System, 6506-E VPN System, 6506-E WLSM Bundle, 6509-E, 6509-E 10Gig Firewall Security System Bundle, 6509-E Application Control Engine (ACE) 20 Bundle, 6509-E Application Control Engine (ACE) 30 8G Bundle, 6509-E chassis with Supervisor Engine 32, 6509-E Data Center Services Bundle, 6509-E Firewall Security System Bundle, 6509-E Firewall Security System Bundle with Supervisor Engine 720-3BXL, 6509-E IPSec VPN SPA Security System, 6509-E NAM-3 System, 6509-E with Supervisor Engine 720, 6509-E with WiSM Bundle, 6509-V-E, 6807-XL |
