Produktdatablad |
|
Enhedstype |
Switch - 48 porte - Administreret - kan stables |
Pakningstype |
Desktop, monterbar på stativ 1U |
Undertype |
Gigabit Ethernet |
Porte |
48 x 10/100/1000 (PoE+) + 4 x SFP |
Power Over Ethernet (PoE) |
PoE+ |
PoE-budget |
390 W |
Præstation |
Omkoblingskapacitet: 176 Gbps ¦ Fremsendelsespræstation: 130.95 Mpps |
Kapacitet |
IPv4 router: 24000 ¦ Virtuelle grænseflader (VLANs): 255 ¦ Switched virtual interfaces (SVIs): 1000 |
MAC adresse table størrelse |
32.000 optegnelser |
Jumborammesupport |
9198 byte |
Routingprotokol |
Statisk IP routing |
Protokol til fjernadministration |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, SSH, CLI |
Autentificeringsmetode |
Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
Egenskaber |
Komplet duplex ydeevne, Layer 2 switching, DHCP-understøttelse, auto-negotiation, understøttet af ARP, trunking, VLAN-understøttet, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog understøttet, IPv6 understøttet, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, MDL snooping, Dynamic ARP Inspection (DAI), Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), LLDP support, Link Aggregation Control Protocol (LACP), MAC Address Notification, Remote Switch Port Analyzer (RSPAN), Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet, Strict Priority Queuing (SPQ), Class of Service (CoS), DiffServ Code Point (DSCP) support |
Overensstemmelsesstandarder |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at |
RAM |
4 GB |
Flashhukommelse |
2 GB |
Statusindikatorer |
Ports transmissionshastighed, dupleksmodus for port, system, aktiv, status, PoE |
Interface |
48 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 1 x USB Type A ¦ 1 x seriel (konsol) RJ-45 administration ¦ 1 x administration (Gigabit LAN) RJ-45 administration ¦ 1 x administration (mini-USB) Type B administration ¦ 4 x 1000Base-X SFP uplink |
Ekspansionsåbninger |
1 (total) / 1 (fri) x Stablingsmodul |
Strømenhed |
Intern strømforsyning - hot-plug |
Antal installeret |
1 |
Maks. antal understøttet |
2 |
Overskudsspænding |
Valgfri |
Skema til overskudsspænding |
1+1 (med valgfrit netaggregat) |
Strømforsyning |
640 Watt |
Nødvendig spænding |
AC 120/230 V (50/60 Hz) |
Rackmonteringspakke |
Inkluderet |
MTBF (forventet tid mellem fejl) |
383,760 timer |
Overensstemmelsesstandarder |
CISPR 22 Klasse A, GOST, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, NOM, EN 61000-3-3, EN55024, EN55022 Klasse A, ICES-003 Klasse A, RoHS, UL 60950-1 Second Edition, KCC, FCC Part 15 A, ISO 7779, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, KN24, KN22 Class A |
Med software |
Cisco IOS LAN Base |
Bredde |
44.5 cm |
Dybde |
44.8 cm |
Højde |
4.4 cm |
Vægt |
7.6 kg |
Service & Support |
Begrænset garanti - ombytning - livstid - responstid: næste forretningsdag ¦ Teknisk understøttelse - telefonrådgivning - 90 dage |
Min. driftstemperatur |
-5 °C |
Maks. driftstemperatur |
45 °C |
Fugtighedsgrad ved brug |
5 - 96 % (ikke-kondenserende) |
Min. lagertemperatur |
-40 °C |
Maks. Opbevaringstemperatur |
70 °C |
