Produktdatablad |
|
| Produkttype |
Bundkort - ATX |
| Chipsættype |
Intel Z170 |
| Processor-socket |
LGA1151 Socket |
| Max antal processorer |
1 |
| Kompatible processorer |
Pentium, Celeron, Core i5, Core i3, Core i7 |
| Maks. størrelse |
64 GB |
| Teknologi |
DDR4 |
| Bus Clock |
2133 MHz, 2800 MHz (O.C.), 2666 MHz (O.C.), 2400 MHz (O.C.), 3000 MHz (O.C.), 3200 MHz (O.C.), 3300 MHz (O.C.), 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3800 MHz (O.C.), 3866 MHz (O.C.) |
| Understøttet RAM-integritetskon |
Ikke-ECC |
| Registreret eller buffer |
Ikke bufferet |
| Egenskaber |
Dobbelt kanal hukommelses arkitektur, Intel Extreme Memory Profiles (XMP) |
| Maks. allokeret RAM-størrelse |
512 MB |
| Type |
HD Audio (8-kanaler) |
| Audio codec |
Realtek ALC1150 |
| Overensstemmelsesstandarder |
DTS Connect, High Definition Audio, DTS Studio Sound |
| Netværk controller |
Intel I219V |
| Netværks interfaces |
Gigabit Ethernet |
| Ekspansionsåbninger |
1 x CPU ¦ 4 x DIMM 288-pins ¦ 2 x PCIe 3.0 x16 (dual x8 mode; single kort: x16 mode) ¦ 1 x PCIe 3.0 x16 (x4-modus) ¦ 4 x PCIe 2.0 x1 |
| Grænseflade (lagring) |
SATA-600 / PCIe 3.0 -stikforbindelser: 6 x 7pin SATA, 1 x M.2, 1 x SATA Express port - RAID 0 / RAID 1 / RAID 10 / RAID 5 |
| RAID-egenskaber |
Intel Smart Response Technology |
| Interface |
1 x HDMI ¦ 1 x DisplayPort ¦ 1 x DVI-D ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x USB 3.1 ¦ 1 x USB-C ¦ 2 x USB 3.0 ¦ 2 x USB 2.0 ¦ 1 x audio linje-ind - mini-jack ¦ 1 x audio linje-ud - mini-jack ¦ 1 x mikrofon - mini-jack ¦ 1 x audio linje-ud (centrum/subwoofer) - mini-jack ¦ 1 x audio linje-ud (bagtil) - mini-jack ¦ 1 x TOSLINK |
| Interne interfaces |
4 x USB 2.0 - intern stik ¦ 4 x USB 3.0 - intern stik ¦ 1 x audio - intern stik ¦ 1 x SPDIF ud - intern stik ¦ 1 x Thunderbolt - intern stik |
| Strømkontakter |
24-pin hovedstrøm-konnektor, 8-pin ATX12V-kontakt |
| BIOS-type (Basic Input/Output System) |
AMI |
| BIOS-egenskaber |
WfM 2.0 understøttet, Flersproget BIOS, ASUS Quiet Thermal Solution, UEFI BIOS, ACPI 5.0 support, ASUS EZ Flash 3, DMI 3,0 support, SMBIOS 3,0 support |
| Sov/ Vågn |
Aktivering af LAN (wake on LAN = WOL), vågn på PME |
| Hardware egenskaber |
C.P.R. (CPU Parameter Recall), jack retasking, ASUS Anti-Surge Protection, MemOK!, ASUS Q-Design, Q-DIMM, GPU Boost, ASUS EZ DIY, Q-LED, Q-Slot, CrashFree BIOS 3, ASUS Q-Connector, audio jack detektions teknologi, ASUS EPU (Energy Processing Unit), ASUS Q-Shield, ASUS Precision Tweaker 2, NVIDIA Quad SLI Technology Support, ASUS 8 Phase Power Design, NVIDIA 2-way SLI Technology Support, Intel Turbo Boost Technology 2.0, ASUS TPU (TurboV Processing Unit), ASUS DIGI+ VRM, Intel Clear Video HD Technology, Fanless Design Heatsink, AMD Quad CrossFireX-teknologisupport, AMD 3-vejs CrossFireX teknologisupport, ASUS DIGI+ Power Control, Intel InTru 3D Technology, Intel Insider, Intel Quick Sync Video, ASUS Remote GO!, DirectKey, Disk Unlocker, ASUS Enhanced DRAM Overcurrent Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), Clear CMOS Button, ASUS Stainless Steel Back I/O, ASUS O.C. Tuner, anti-popfunktion, Turbo LAN, ASUS Fan Xpert 3, Dual Intelligent Processors 5, LANGuard, Memory O.C. Design, USB 3.1 Boost, ASUS Overvoltage Protection, ASUS Crystal Sound 3, ASUS PRO Clock Technology, ASUS 5X Protection II |
| Udstyr inkluderet |
1 x M.2 skrue, I/O-bagdække |
| Medfølgende ledninger |
4 x Seriel ATA kabel ¦ 1 x SLI bro |
| Med software |
ASUS Auto Tuning, ASUS AI Charger, ASUS AI Suite III, ASUS EZ Update, ASUS Turbo App, Antivirus (OEM version), Mobo Connect, PC Cleaner, Media Streamer, HyStream |
| Kompatibel med Windows 7 |
Udstyr og software der er "Kompatibel med Windows 7" har Microsofts forsikring i at disse produkter har bestået kompatibilitets- og pålidelighedsprøver med 32-bit og 64-bit Windows 7. |
| Overensstemmelsesstandarder |
Plug and Play |
| Bredde |
30.5 cm |
| Dybde |
24.4 cm |
