Produktdatablad |
|
| Produkttype |
Bundkort - ATX |
| Chipsættype |
Intel X299 |
| Processor-socket |
LGA2066 Socket |
| Max antal processorer |
1 |
| Kompatible processorer |
Core X |
| Maks. størrelse |
64 GB |
| Teknologi |
DDR4 |
| Bus Clock |
2400 MHz, 2133 MHz, 2666 MHz, 2800 MHz (O.C.), 2933 MHz (O.C.), 3200 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3800 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4500 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.) |
| Understøttet RAM-integritetskon |
Ikke-ECC |
| Registreret eller buffer |
Ikke bufferet |
| Egenskaber |
Quad kanal hukommelses arkitektur, Intel Extreme Memory Profiles (XMP) 2.0 |
| Type |
HD Audio (8-kanaler) |
| Audio codec |
Realtek ALC1220 |
| Overensstemmelsesstandarder |
DTS Connect, High Definition Audio, Premium Blu-ray audiosupport, Purity Sound 4 |
| Netværk controller |
Intel I219V / I211-AT |
| Netværks interfaces |
2 x Gigabit Ethernet |
| Ekspansionsåbninger |
1 x CPU ¦ 4 x DIMM 288-pins ¦ 5 x PCIe 3.0 x16 (44-lane CPU (x16/x0/x0/x16/x8, x8/x8/x8/x8/x8 modes), 28-lane CPU (x16/x0/x0/x8/x4, x8/x8/x0/x8/x4 modes), 16-lane CPU (x16/x0/x0/x0/x4, x8/x0/x0/x8/x4 modes)) ¦ 1 x PCIe 2.0 x1 ¦ 1 x PCIe 3.0 x4 |
| Grænseflade (lagring) |
SATA-600 -stikforbindelser: 6 x 7-pin Seriel ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ ASMedia ASM1061: SATA-600 -stikforbindelser: 2 x 7-pin Seriel ATA ¦ SATA-600 / PCIe 3.0 -stikforbindelser: 2 x Ultra M.2 |
| RAID-egenskaber |
Intel Smart Response Technology |
| Interface |
1 x PS/2-tastatur/mus ¦ 4 x USB 3.1 Gen 1 ¦ 2 x USB 2.0 ¦ 1 x TOSLINK ¦ 1 x USB 3.1 Gen 2 ¦ 1 x USB-C Gen2 ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x audio linje-ud (bagtil) - mini-jack ¦ 1 x audio linje-ud (centrum/subwoofer) - mini-jack ¦ 1 x audio linje-ind - mini-jack ¦ 1 x audio linje-ud - mini-jack ¦ 1 x mikrofon - mini-jack |
| Interne interfaces |
4 x USB 2.0 - intern stik ¦ 2 x USB 3.1 Gen 1 - intern stik ¦ 1 x audio - intern stik ¦ 1 x Thunderbolt - intern stik ¦ 1 x USB-C Gen2 - intern stik |
| Strømkontakter |
4-pin ATX12V konnektor, 24-pin hovedstrøm-konnektor, 8-pin ATX12V-kontakt, 6-pins ATX12V stikforbindelse |
| BIOS-type (Basic Input/Output System) |
AMI |
| BIOS-egenskaber |
Flersproget BIOS, BIOS FlashBack, UEFI BIOS, Dual BIOS, Secure Backup UEFI Technology, SMBIOS 3,0 support, ACPI 6,1 support |
| Hardwareovervågning |
CPU kernetemperatur, chassis temperatur, takometer til CPU-blæser, takometer til chassis-blæser, systemspænding, CPU kerne-spænding |
| Sov/ Vågn |
Aktivering af LAN (wake on LAN = WOL) |
| Hardware egenskaber |
Understøttelse af NVIDIA SLI-teknologi, ASRock Instant Flash, NVIDIA 3-way SLI Technology Support, NVIDIA Quad SLI Technology Support, 15µ Gold Contact, ASRock XFast LAN, ASRock Dr. Debug, NVIDIA 4-way SLI Technology Support, Dual LAN Teaming, ASRock Crashless BIOS, AMD CrossFireX-teknologisupport, AMD Quad CrossFireX-teknologisupport, AMD 3-vejs CrossFireX teknologisupport, ASRock Internet Flash, Digi Power Design, AMD 4-vejs CrossFireX teknologisupport, ESD Protection, ASRock UEFI System Browser, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), ASRock UEFI Tech Service, 8 Layer PCB, NickShih's OC Profile, Timing Configurator, ASRock Formula Drive, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Easy RAID Installer, Dr.MOS MOSFET, XXL Aluminum Alloy Heatsink, ASRock Live Update, ASRock EZ Mode, Intel Optane Memory Ready, ASRock Ultra M.2, Nichicon 12K Black Caps, Matte Black PCB, ASRock Steel Slots, ASRock Purity Sound 4, 13 Phase Power Design, ASRock RGB LED, ASRock Ultra USB Power, 2oz Copper PCB, ASRock Hyper BCLK Engine III, ASRock OC Formula Power Kit, ASRock OC Formula Connector Kit, ASRock OC Formula Cooling Kit, ASRock OC Formula Monitor Kit, Intel Turbo Boost Max Technology 3.0 |
| Udstyr inkluderet |
I/O- bagvæg, 2 x M.2 skruer, ASRock SLI_HB_Bridge_3S Card, ASRock 3-Way SLI-3S1S Bridge Card, ASRock 4-Way SLI-S111 Bridge Card |
| Medfølgende ledninger |
4 x Seriel ATA kabel ¦ 1 x 3-vejs SLI bro |
| Med software |
Drivers & Utilities, Antivirus (prøveversion), Google Chrome Browser, Google ChromeToolbar, ASRock RGB LED, ASRock XFast LAN |
| Overensstemmelsesstandarder |
FCC, EuP Ready, ErP Ready |
| Bredde |
30.5 cm |
| Dybde |
24.4 cm |
| Service & Support |
Begrænset garanti - 3 år |
